Precision Manufacturing, Consistent Output—Built on 20 Years of Expertise
This is a dual-purpose machine with multiple functions; it can be used to make complete rigid box as well as to make hard cover.
| Speed: | 27pcs/min |
| Facial paper pile heigh: | 550mm |
| Cardboard pile height: | 1380mm |
This gift box making machine adopting servo control system, photoelectric correction positioning system, and human-machine interface intelligent system for the whole machine.It has the advantage of completing multiple processes at once, including automatic glue feeding, gluing, gray board positioning, correction, finished product, and bubble pressing.This intelligent rigid box making machine is different from other machines. The machine can use hard case positioning to make flip style gift packaging boxes, or it can be regarded as a set of automatic hard case box making machine.
1. This automatic gift box making machine use glue viscosity meter,the glue will evenly cover, the paper the glue stickiness which ensures the quality of finished products.
2. Servo controlled paper feeder adopts post-sucking pre-pushing type to convey paper which efficiently avoids two pieces of paper entering into the machine.This can greatly avoid estimation during the operation of gift box making machine, greatly reduce the probability of downtime, and ensure the completion of daily production.
3. Camera positioning system and digital adjustment of sizes can significantly improve the precision of box production.
4. The optional hard case positioning function makes this gift box forming machine multifunctional, which can meet various production needs of customers and reduce machine operating costs.
5. This gift box forming machine is suitable for producing various high-end paper boxes, wine boxes, makeup boxes, electronic product boxes, etc.
 |
 |
 |
|
Cosmetics-Drawer-Box |
Drawer-Box-with-Ribbon |
Jewelry-Drawer-Box |
|
Model |
RSK-600MF |
|
Box size (W*L) |
Min.50*100 Max.400*500 |
|
Paper size (A*B) |
Min.70*130 Max.620*1040 |
|
Cover size |
Min.70*130 Max.540*1000 |
|
Box height (H) |
12-130mm |
|
Turn in fold size(R) |
10-80mm |
|
Folded ear size |
10-80mm |
|
Paper thickness |
100-300g/m² |
|
Board thickness |
0.8-3mm |
|
Number of sheets |
5pcs |
|
Paper Stack height |
550mm |
|
Board stack height |
1380mm |
|
Production speed |
22-27pcs/min |
|
Motor power |
12kw |
|
Electric heating power |
10kw |
|
Air source requirement |
50L/min 0.6Mpa |
|
Machine weight |
5500kg |
|
Machine size |
L6500*W5000*H3100mm |
We use internationally advanced technology and well-known brands of electrical appliances to manufacture machines. If the machines do not meet the customer's expectations, we will not leave the factory.
Weak creases typically occur due to insufficient creasing pressure, blunt or misaligned creasing blades, or unsuitable paper quality. Adjust the creasing pressure according to the paper thickness, inspect and sharpen or replace creasing blades regularly, and verify that the paper stock meets the recommended specifications for folding endurance.
Adhesive issues may stem from incorrect glue application settings, clogged nozzles, or improper glue viscosity. Check and clean the glue nozzles routinely, adjust the glue amount and application timing based on box size, and ensure the adhesive viscosity is suitable for the paper type. Also, maintain consistent machine speed to allow proper adhesive setting.
Absolutely. Our machines are not one-size-fits-all. We tailor the forming heads, feeder system, and machine footprint to your exact box dimensions and required speed (CPH). Whether you need a compact unit for short runs or a high-speed line for mass production, we engineer the optimal solution.
Yes, that's our specialty. We customize the creasing, folding, and glueing stations to suit your material's properties. By adjusting pressures, temperatures, and application methods, we guarantee flawless formation for your specific paper stock, eliminating cracking or misalignment.
Yes, it's designed for adaptability. Our core architecture is modular. You can later upgrade or reconfigure modules (e.g., adding a window-patching unit or a hot-foil stamping station) to accommodate new box designs. This protects your investment and ensures long-term relevance.
